Kubernetes on K5 – Made Easy

So I’m back from the Boston OpenStack Summit almost 2 weeks now – what a fun week for a geek. Eating, drinking and sleeping technology…I love it. It was great to meet so many fellow geeks and nice to learn what customers are discovering on their various cloud journeys. If anyone wishes to see a re-run of my Fujitsu Cloud Service K5 presentation you can check it out on youtube here – (I definitely need to shed a few lbs)

A prevalent theme at this OpenStack Summit was how Kuberenetes and OpenStack are  good companions, just like strawberry jam and cream – anyone for a cream tea…it’s almost summer.

However the great British cream tea debate lives on…

straeberriesandcream

Some folks want to use Kubernetes to deploy OpenStack as a ‘kube’ application whilst others see Kubernetes as the container orchestration layer on top of OpenStack. I can see merit in both routes but will sit on the fence until the community decides if there’s ever going to be a definitive winner. Either way these will be complex solutions to debug when something goes wrong – whomever has the simplest self healing tooling will win this race in my opinion.

Infrastructure as Code – OpenStack Heat Templates to Deploy Kubernetes

In the following example I’ve built a heat stack that deploys Kubernetes on top of Fujitsu Cloud Service K5 IaaS. The heat stack builds out the pre-requisite infrastructure in K5 and then one of the deployed servers leverages the Kubernetes Kargo Project which uses an ansible-playbook to install and configure the Kubernetes PaaS layer.

I’ve provided you with a choice of 2 templates:

  • Simple, non-HA 3+1 server deployment. Suitable to evaluate Kubernetes and deploy applications.
heat_template_version: 2013-05-23
# Author: Graham Land
# Date: 26/05/2017
# Purpose: Deploy Kubernetes on Fujitsu's K5 IaaS Platform
#
# Twitter: @allthingsclowd
# Blog: https://allthingscloud.eu
# Gist: https://gist.github.com/allthingsclowd/4814fb3895ef5842befbb90cdf93244e
#
description: Simple Kubernetes Non HA Deployment
# Input parameters
parameters:
k5_image:
type: string
label: Image name or ID
description: Image to be used for compute instance
default: "CentOS 7.2 64bit (English) 02"
flavor:
type: string
label: Flavor
description: Type of instance (flavor) to be used
default: "S-1"
key_az_1:
type: string
label: Key name
description: Name of key-pair to be used for compute instance
default: "KUBE-KP-AZ1"
public_net_az1:
type: string
label: external network ID
description: Public network
default: "73598426-3678-4eb6-8131-9007770d3ccd"
az1:
type: string
label: Availability Zone
description: Region AZ to use
default: "de-1a"
az1_dns:
type: string
label: Availability Zone DNS Servers
description: Availability Zone DNS Servers to use
default: ["185.149.225.9", "185.149.225.10"]
my_ip:
type: string
label: External management IP
description: IP address allowed for access to jump server on SSH
default: "165.120.203.180/32"
kube_router:
type: string
label: Kubernetes Router Used to Provide External Access to VMs
description: Kubernetes Router Used to Provide External Access to VMs
default: "020d1ecc-0fd5-40ec-aa69-cc49e7eb98b1"
default_security_group:
type: string
label: Kubernetes Router Used to Provide External Access to VMs
description: Kubernetes Router Used to Provide External Access to VMs
default: "0b816413-cba5-4163-b809-73faf8d598c7"
kube_service_network:
type: string
label: Kube services network
description: Kubernetes Services Network
default: "10.233.0.0/18"
kube_pod_network:
type: string
label: Kube pods network
description: Kubernetes Pods Network
default: "10.233.64.0/18"
# K5 Infrastructure resources to be built
resources:
# Create a private network in availability zone 1
kube_private_net_az1:
type: OS::Neutron::Net
properties:
availability_zone: { get_param: az1 }
name: "kube_private_net1"
# Create a new subnet on the private network
kube_private_subnet_az1:
type: OS::Neutron::Subnet
depends_on: kube_private_net_az1
properties:
availability_zone: { get_param: az1 }
name: "Kube_private_subnet_az1"
network_id: { get_resource: kube_private_net_az1 }
cidr: "192.168.200.0/24"
gateway_ip: "192.168.200.254"
allocation_pools:
start: "192.168.200.100"
end: "192.168.200.150"
dns_nameservers: ["185.149.225.9", "185.149.225.10"]
# Connect an interface on the web tier network's subnet to the router
az1_router_interface:
type: OS::Neutron::RouterInterface
depends_on: [kube_private_subnet_az1]
properties:
router_id: { get_param: kube_router }
subnet_id: { get_resource: kube_private_subnet_az1 }
# Create jump server security group
jump_security_group:
type: OS::Neutron::SecurityGroup
properties:
description: kube stack jump server security group
name: kube-jumpbox
rules:
# allow inbound ssh from my ip
remote_ip_prefix: { get_param: my_ip }
protocol: tcp
port_range_min: 22
port_range_max: 22
remote_ip_prefix: { get_param: my_ip }
protocol: icmp
# Create lbaas server security group
app_frontend_security_group:
type: OS::Neutron::SecurityGroup
properties:
description: kube stack network connector security group
name: sock-shop-frontend
rules:
# allow http traffic to etcd sock-shop service
remote_ip_prefix: "0.0.0.0/0"
protocol: tcp
port_range_min: 30001
port_range_max: 30001
################### JumpBox – AZ 1 ######################################################################
# Create a new port for the server interface, assign an ip address and security group
jump-server-port:
type: OS::Neutron::Port
depends_on: [ jump_security_group ]
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
security_groups: [{ get_resource: jump_security_group }, { get_param: default_security_group }]
# Allocate a floating/global ip address
jump-server-floating-ip:
type: OS::Neutron::FloatingIP
properties:
availability_zone: { get_param: az1 }
floating_network_id: { get_param: public_net_az1 }
# Assign a floating/global ip address to the fixed server ip address
jump-server-floating-ip-association:
type: OS::Neutron::FloatingIPAssociation
depends_on: jump-server-floating-ip
properties:
floatingip_id: { get_resource: jump-server-floating-ip }
port_id: { get_resource: jump-server-port }
# Create a system volume for use with the server
jump-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "jump-box-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
jump-server:
type: OS::Nova::Server
depends_on: [ etcd1-server, worker1-server, worker2-server, jump-server-port ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: jump-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
# Create private key file to enable SSH to remaining servers in the environment
user_data_format: RAW
user_data:
str_replace:
template: |
#cloud-config
write_files:
– path: /root/.ssh/id_rsa
content: |
—–BEGIN RSA PRIVATE KEY—–
MIIEoQIBAAKCAQEA4MBSCRr6XOdLBsVSF3x3X/Y+jSoCP4walw5x/8A9g+kF9vuC
lBU32TlQD/k1B4mxODhxTi1pzmw7Se/ccu3dlGivRgKuQzplVMeCJKAd15MxTr8i
9ZKlwEj02xxBIzl58pVlHGIGVLwzxyfKtzOSFkEVdUYmJUvifoTYM5R5aWPI2Rhh
hvkxtmz+WHC67dePcrzAaE0KizRWF4xRP/ZFUXUwcB/Z2fbF5RPocARBjbZgKDb4
ufC0v9eKdn6mDQDu/Vq7VY8058efitNcfqxhx5d+t0EpwZCha6J7/3KJa9rXABzH
WrVt1Tk/1F/Z8h/VNyo0k1KLMlBlsHZH5BSMgQIBIwKCAQBmvlFjP4hk/AUKaNUS
DQNfEXuuPxb4eo/QBpqDixTOlmkgcvndS4c+ux1JIXdT5yxxeONW8DBeXVzumYlZ
HEgJVG1h1Vb6KVLk7X1SklbI8tS2SL+GNGkHcc8FFDsIydFY89ZzYALk6FIvKCIn
3Q+VJREfqwofraleaJ1ZaHIESgPzzPHoVc9//51rtqc2pjmmCu3BsJkR8isAiiyL
LiegC9FIcXXGcgeMWqFBPqHUELcZXTaUYIu/Ie8FBvDXiZMWOQFbemQJczF8BS3j
YFoGXoY6c8y052ekh8FGziJgy35gHf3ygUMnaVLirJpG0i3SH3M0ZHkVeP8fcw5x
uFFLAoGBAPqx+ubMIM/tH4X+zUD7mgaX8+EByd8IUKLwVTXGS7XzuAnkVTBr58bC
AOCtKX9oLcR40J3Y5N0rzZRmzs7+YNXnK2VQTYbZFPWfD6giKuy+JFc+5Ej+Men/
dOviiF74V8dsHtSwjX/CStzLYdEy6+xyA3Q0USPeVAQKvXDlOe27AoGBAOWBzSmO
nKvhTk/+A+wqseq/kPdO0NyrofUWCNoJNZivo0y9UnfL9Y6gDMcEIcAlpAsn6nN8
eKXh77s0sKg3IydVkqMNJfM6Bq2seF/7HrAbhGHYf5D3pIS0RJlSBz8/xeshvFcn
rSsst/25JHdESCSJgfRcZZ51A7OQ7SdmF2zzAoGBAKS+Gegfvcp3QJnh9Jhq0u5j
2scPzc0UF7uH/Xsb6Jwj0LYLE2j2c70gZvoLZGmq3D9IFA/07irw5i5SMCGf2Twb
kYu4bXXfHGbk3mcsZVm+x2yIaiFWldRIyS1LuLNv/ytHDPIq4KRpvCqxiWw3Z9Xk
he1G8334gFptdSzuZ+VdAoGAVT7XLLFQIpWDfMwQFeP48MrPcczRPAU8J9T7+Tae
4PDHoCkQAJw2orB5xkNc/jnd2EIGn+xnU45u/GQHGeiYB0urfmP4JyQuXcO3rp8a
BuWmMvikaQuGP+svbCXILW91ZfaWaYPD+hfskXCnJPway74Lsoi4B6fOLMDNHUMt
RbkCgYAi4KlL+fT5xJ9X3EbYxQ4P2TAEUAwKh7yvpoFVH/OuKZedIi2sHNOkb895
qlcmVtbD96T0m4sZ2UVk0oDURsjp7tK8pIdCqXkxx+Y/cSEc+1R/3J0GcUHt2cbc
YmDPfr1iqizT0n9em0B51SQb3UH88Egf56GHXiVaEZYc7/o0DQ==
—–END RSA PRIVATE KEY—–
– path: /home/k5user/kubernetes.cfg
content: |
[etcd]
$etcd1_az1_ip
[kube-master]
$etcd1_az1_ip
[kube-node]
$worker1_az1_ip
$worker2_az1_ip
[k8s-cluster:children]
kube-node
kube-master
runcmd:
– chmod 0600 /root/.ssh/id_rsa
– yum makecache fast
– yum install -y git
– yum install -y epel-release
– yum install -y ansible
– yum install -y python-netaddr
– yum install -y python-pip
– pip install –upgrade pip
– pip install –upgrade jinja2
– mkdir -p /home/k5user/kubernetes/kargo
– git clone https://github.com/kubernetes-incubator/kargo.git /home/k5user/kubernetes/kargo
– cd /home/k5user/kubernetes/kargo
– git reset –hard 9e64267
– cp /home/k5user/kubernetes.cfg /home/k5user/kubernetes/kargo/inventory/inventory.cfg
– ansible-playbook -u k5user -b -i inventory/inventory.cfg cluster.yml
– ssh k5user@$etcd1_az1_ip 'kubectl create -f "https://github.com/microservices-demo/microservices-demo/blob/master/deploy/kubernetes/complete-demo.yaml?raw=true"'
– ssh k5user@$etcd1_az1_ip 'kubectl version && kubectl get nodes && kubectl get pods –all-namespaces && sudo docker ps'
params:
$etcd1_az1_ip: { get_attr: [ etcd1-server, first_address ] }
$worker1_az1_ip: { get_attr: [ worker1-server, first_address ] }
$worker2_az1_ip: { get_attr: [ worker2-server, first_address ] }
message: "Installation Complete"
name: "kube-jumpbox-az1"
networks:
port: { get_resource: jump-server-port }
##########################################################################################################
################### Kube etcd master 1 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
etcd1-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
security_groups: [{ get_resource: app_frontend_security_group }, { get_param: default_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Allocate a floating/global ip address
etcd1-server-floating-ip:
type: OS::Neutron::FloatingIP
properties:
availability_zone: { get_param: az1 }
floating_network_id: { get_param: public_net_az1 }
# Assign a floating/global ip address to the fixed server ip address
etcd1-server-floating-ip-association:
type: OS::Neutron::FloatingIPAssociation
depends_on: jump-server-floating-ip
properties:
floatingip_id: { get_resource: etcd1-server-floating-ip }
port_id: { get_resource: etcd1-server-port }
# Create a system volume for use with the server
etcd1-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "etcd1-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
etcd1-server:
type: OS::Nova::Server
# depends_on: [ jump-server,etcd3-server,etcd1-server-port,etcd1-sys-vol ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: etcd1-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "etcd1_az1"
networks:
port: { get_resource: etcd1-server-port }
###########################################################################################################
################### worker 1 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
worker1-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
# security_groups: [{ get_resource: web_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
worker1-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "worker1-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
worker1-server:
type: OS::Nova::Server
# depends_on: [ jump-server ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: worker1-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "worker1_az1"
networks:
port: { get_resource: worker1-server-port }
###########################################################################################################
################### worker 2 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
worker2-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
# security_groups: [{ get_resource: web_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
worker2-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "worker2-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
worker2-server:
type: OS::Nova::Server
# depends_on: [ jump-server ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: worker2-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "worker2_az1"
networks:
port: { get_resource: worker2-server-port }
###########################################################################################################

  • Highly Available, multi K5 AZ 6+1 server deployment. Suitable to evaluate a clustered etcd Kubernetes and deploy applications.
heat_template_version: 2013-05-23
# Author: Graham Land
# Date: 26/05/2017
# Purpose: Deploy Kubernetes on Fujitsu's K5 IaaS Platform
#
# Twitter: @allthingsclowd
# Blog: https://allthingscloud.eu
#
#
description: Highly Available (multiple etcd & minions across AZs) Kubernetes Cluster
# Input parameters
parameters:
k5_image:
type: string
label: Image name or ID
description: Image to be used for compute instance
default: "CentOS 7.2 64bit (English) 02"
flavor:
type: string
label: Flavor
description: Type of instance (flavor) to be used
default: "S-1"
key_az_1:
type: string
label: Key name
description: Name of key-pair to be used for compute instance
default: "KUBE-KP-AZ1"
key_az_2:
type: string
label: Key name
description: Name of key-pair to be used for compute instance
default: "KUBE-KP-AZ2"
public_net_az1:
type: string
label: external network ID
description: Public network
default: "73598426-3678-4eb6-8131-9007770d3ccd"
public_net_az2:
type: string
label: external network ID
description: Public network
default: "58e863e5-7d31-4f32-9178-370a3288db42"
az1:
type: string
label: Availability Zone
description: Region AZ to use
default: "de-1a"
az2:
type: string
label: Availability Zone
description: Region AZ to use
default: "de-1b"
my_ip:
type: string
label: External management IP
description: IP address allowed for access to jump server on SSH
default: "86.187.115.18/32"
kube_router:
type: string
label: Kubernetes Router Used to Provide External Access to VMs
description: Kubernetes Router Used to Provide External Access to VMs
default: "020d1ecc-0fd5-40ec-aa69-cc49e7eb98b1"
kube_router_az2:
type: string
label: Kubernetes Router Used to Provide External Access to VMs
description: Kubernetes Router Used to Provide External Access to VMs
default: "b48771b7-3fcc-4da1-b925-d3cbfe641381"
default_security_group:
type: string
label: Kubernetes Router Used to Provide External Access to VMs
description: Kubernetes Router Used to Provide External Access to VMs
default: "0b816413-cba5-4163-b809-73faf8d598c7"
kube_service_network:
type: string
label: Kube services network
description: Kubernetes Services Network
default: "10.233.0.0/18"
kube_pod_network:
type: string
label: Kube pods network
description: Kubernetes Pods Network
default: "10.233.64.0/18"
# K5 Infrastructure resources to be built
resources:
# Create a private network in availability zone 1
kube_private_net_az1:
type: OS::Neutron::Net
properties:
availability_zone: { get_param: az1 }
name: "kube_private_net1"
# Create a new subnet on the private network
kube_private_subnet_az1:
type: OS::Neutron::Subnet
depends_on: kube_private_net_az1
properties:
availability_zone: { get_param: az1 }
name: "Kube_private_subnet_az1"
network_id: { get_resource: kube_private_net_az1 }
cidr: "192.168.200.0/24"
gateway_ip: "192.168.200.254"
allocation_pools:
start: "192.168.200.100"
end: "192.168.200.150"
dns_nameservers: ["185.149.225.9", "185.149.225.10"]
host_routes: [{"nexthop": "192.168.200.253", "destination": "10.11.200.0/24"}]
# Connect an interface on the web tier network's subnet to the router
az1_router_interface:
type: OS::Neutron::RouterInterface
depends_on: [kube_private_subnet_az1]
properties:
router_id: { get_param: kube_router }
subnet_id: { get_resource: kube_private_subnet_az1 }
# Create another private network in availability zone 1
kube_private_net_az2:
type: OS::Neutron::Net
properties:
availability_zone: { get_param: az2 }
name: "kube_private_net2"
# Create a new subnet on the private network
kube_private_subnet_az2:
type: OS::Neutron::Subnet
depends_on: kube_private_net_az2
properties:
availability_zone: { get_param: az2 }
name: "kube_private_subnet_az2"
network_id: { get_resource: kube_private_net_az2 }
cidr: "10.11.200.0/24"
gateway_ip: "10.11.200.254"
allocation_pools:
start: "10.11.200.100"
end: "10.11.200.150"
dns_nameservers: ["185.149.227.9", "185.149.227.10"]
host_routes: [{"nexthop": "10.11.200.253", "destination": "192.168.200.0/24"}]
# Connect an interface on the web tier network's subnet to the router
az2_router_interface:
type: OS::Neutron::RouterInterface
depends_on: [kube_private_subnet_az2]
properties:
router_id: { get_param: kube_router_az2 }
subnet_id: { get_resource: kube_private_subnet_az2 }
# Create jump server security group
jump_security_group:
type: OS::Neutron::SecurityGroup
properties:
description: kube stack jump server security group
name: kube-jumpbox
rules:
# allow inbound ssh from my ip
remote_ip_prefix: { get_param: my_ip }
protocol: tcp
port_range_min: 22
port_range_max: 22
remote_ip_prefix: { get_param: my_ip }
protocol: icmp
# Create network connector server security group
nc_security_group:
type: OS::Neutron::SecurityGroup
properties:
description: kube stack network connector security group
name: kube-network-connector
rules:
# allow full tcp and udp communication internally
remote_ip_prefix: "0.0.0.0/0"
protocol: tcp
remote_ip_prefix: "0.0.0.0/0"
protocol: udp
remote_ip_prefix: "0.0.0.0/0"
protocol: icmp
# Create lbaas server security group
lbaas_security_group:
type: OS::Neutron::SecurityGroup
properties:
description: kube stack network connector security group
name: kube-load-balancer
rules:
# allow http traffic to etcd sock-shop service
remote_ip_prefix: "0.0.0.0/0"
protocol: tcp
port_range_min: 30001
port_range_max: 30001
remote_ip_prefix: "0.0.0.0/0"
protocol: tcp
port_range_min: 80
port_range_max: 80
############################### AZ Interconnect ###########################################################
az1_nc_port:
type: OS::Neutron::Port
depends_on: [ nc_security_group ]
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
security_groups: [{ get_param: default_security_group }]
fixed_ips:
subnet_id: { get_resource: kube_private_subnet_az1 }
ip_address: '192.168.200.253'
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
az2_nc_port:
type: OS::Neutron::Port
depends_on: [ nc_security_group ]
properties:
availability_zone: { get_param: az2 }
network_id: { get_resource: kube_private_net_az2 }
security_groups: [{ get_param: default_security_group }]
fixed_ips:
subnet_id: { get_resource: kube_private_subnet_az2 }
ip_address: '10.11.200.253'
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
az1_network_connector:
type: FCX::Neutron::NetworkConnector
depends_on: [ az1_nc_port,az2_nc_port ]
properties:
name: "kube_connector"
az1_nc_endpoint:
type: FCX::Neutron::NetworkConnectorEndpoint
depends_on: [ az1_nc_port,az2_nc_port ]
properties:
endpoint_type: "availability_zone"
name: "kube_ep_az1"
network_connector_id: { get_resource: az1_network_connector }
location: { get_param: az1 }
az2_nc_endpoint:
type: FCX::Neutron::NetworkConnectorEndpoint
depends_on: [ az1_nc_port,az2_nc_port ]
properties:
endpoint_type: "availability_zone"
name: "kube_ep_az2"
network_connector_id: { get_resource: az1_network_connector }
location: { get_param: az2 }
az1_endpoint_connection:
type: FCX::Neutron::NetworkConnectorEndpointConnection
depends_on: [ az1_nc_port,az2_nc_port ]
properties:
port_id: { get_resource: az1_nc_port }
network_connector_endpoint_id: { get_resource: az1_nc_endpoint }
az2_endpoint_connection:
type: FCX::Neutron::NetworkConnectorEndpointConnection
depends_on: [ az1_nc_port,az2_nc_port ]
properties:
port_id: { get_resource: az2_nc_port }
network_connector_endpoint_id: { get_resource: az2_nc_endpoint }
#########################################################################################################
# AZ Load Balancer
Kube_LBaaS:
type: FCX::ExpandableLoadBalancer::LoadBalancer
depends_on: [ worker1-server, worker2-server, worker3-server ]
properties:
Subnets: [{get_resource: kube_private_subnet_az1}, {get_resource: kube_private_subnet_az2}]
Instances: [{get_resource: worker1-server}, {get_resource: worker2-server}, {get_resource: worker3-server}]
Listeners:
{LoadBalancerPort: '80',
InstancePort: '30001',
Protocol: 'HTTP',
InstanceProtocol: 'HTTP' }
HealthCheck: {Target: 'HTTP:30001/index.html',
HealthyThreshold: '3',
UnhealthyThreshold: '5',
Interval: '30',
Timeout: '5'}
Version: 2014-09-30
Scheme: public
LoadBalancerName: kubelbaas
SecurityGroups: [ {get_resource: lbaas_security_group} ]
# ################### JumpBox – AZ 1 ######################################################################
################### JumpBox – AZ 1 ######################################################################
# Create a new port for the server interface, assign an ip address and security group
jump-server-port:
type: OS::Neutron::Port
depends_on: [ jump_security_group ]
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
security_groups: [{ get_resource: jump_security_group }, { get_param: default_security_group }]
# Allocate a floating/global ip address
jump-server-floating-ip:
type: OS::Neutron::FloatingIP
properties:
availability_zone: { get_param: az1 }
floating_network_id: { get_param: public_net_az1 }
# Assign a floating/global ip address to the fixed server ip address
jump-server-floating-ip-association:
type: OS::Neutron::FloatingIPAssociation
depends_on: jump-server-floating-ip
properties:
floatingip_id: { get_resource: jump-server-floating-ip }
port_id: { get_resource: jump-server-port }
# Create a system volume for use with the server
jump-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "Kube-JumpBox"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
jump-server:
type: OS::Nova::Server
depends_on: [ etcd1-server, etcd2-server, etcd3-server, worker1-server, worker2-server, worker3-server, jump-server-port ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: jump-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
# Create private key file to enable SSH to remaining servers in the environment
user_data_format: RAW
user_data:
str_replace:
template: |
#cloud-config
write_files:
– path: /root/.ssh/id_rsa
content: |
—–BEGIN RSA PRIVATE KEY—–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—–END RSA PRIVATE KEY—–
– path: /home/k5user/kubernetes.cfg
content: |
[etcd]
$etcd1_az1_ip
$etcd2_az1_ip
$etcd3_az2_ip
[kube-master]
$etcd1_az1_ip
[kube-node]
$worker1_az1_ip
$worker2_az1_ip
$worker3_az2_ip
[k8s-cluster:children]
kube-node
kube-master
runcmd:
– chmod 0600 /root/.ssh/id_rsa
– yum makecache fast
– yum install -y git
– yum install -y epel-release
– yum install -y ansible
– yum install -y python-netaddr
– yum install -y python-pip
– pip install –upgrade pip
– pip install –upgrade jinja2
– mkdir -p /home/k5user/kubernetes/kargo
– git clone https://github.com/kubernetes-incubator/kargo.git /home/k5user/kubernetes/kargo
– cp /home/k5user/kubernetes.cfg /home/k5user/kubernetes/kargo/inventory/inventory.cfg
– cd /home/k5user/kubernetes/kargo
– ansible-playbook -u k5user -b -i inventory/inventory.cfg cluster.yml
– sleep 180
– ssh k5user@$etcd1_az1_ip 'kubectl create -f "https://github.com/microservices-demo/microservices-demo/blob/master/deploy/kubernetes/complete-demo.yaml?raw=true"'
– sleep 180
– ssh k5user@$etcd1_az1_ip 'kubectl get cs && kubectl cluster-info dump && kubectl version && kubectl get nodes && kubectl get pods –all-namespaces && sudo docker ps'
– ssh k5user@$etcd3_az2_ip 'kubectl get cs && kubectl cluster-info dump && kubectl version && kubectl get nodes && kubectl get pods –all-namespaces && sudo docker ps'
– ssh k5user@$etcd2_az1_ip 'kubectl get cs && kubectl cluster-info dump && kubectl version && kubectl get nodes && kubectl get pods –all-namespaces && sudo docker ps'
params:
$etcd1_az1_ip: { get_attr: [ etcd1-server, first_address ] }
$etcd2_az1_ip: { get_attr: [ etcd2-server, first_address ] }
$etcd3_az2_ip: { get_attr: [ etcd3-server, first_address ] }
$worker1_az1_ip: { get_attr: [ worker1-server, first_address ] }
$worker2_az1_ip: { get_attr: [ worker2-server, first_address ] }
$worker3_az2_ip: { get_attr: [ worker3-server, first_address ] }
message: "Installation Complete"
name: "kube-jumpbox-az1"
networks:
port: { get_resource: jump-server-port }
##########################################################################################################
################### Kube etcd master 1 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
etcd1-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
# security_groups: [{ get_param: default_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
etcd1-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "etcd1-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
etcd1-server:
type: OS::Nova::Server
# depends_on: [ jump-server,etcd3-server,etcd1-server-port,etcd1-sys-vol ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: etcd1-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "etcd1_az1"
networks:
port: { get_resource: etcd1-server-port }
###########################################################################################################
################### Kube etcd master 2 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
etcd2-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
# security_groups: [{ get_resource: web_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
etcd2-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "etcd2-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
etcd2-server:
type: OS::Nova::Server
# depends_on: [ jump-server,etcd3-server,etcd1-server-port,etcd1-sys-vol ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: etcd2-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "etcd2_az1"
networks:
port: { get_resource: etcd2-server-port }
###########################################################################################################
################### Kube etcd master 3 – Net 1 – AZ2 #####################################################
etcd3-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az2 }
network_id: { get_resource: kube_private_net_az2 }
#security_groups: [{ get_param: default_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
etcd3-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az2 }
name: "etcd3-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
etcd3-server:
type: OS::Nova::Server
# depends_on: [ jump-server ]
properties:
key_name: { get_param: key_az_2 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: etcd3-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "etcd3_az2"
networks:
port: { get_resource: etcd3-server-port }
###########################################################################################################
################### worker 1 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
worker1-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
security_groups: [{ get_resource: lbaas_security_group }, { get_param: default_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
worker1-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "worker1-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
worker1-server:
type: OS::Nova::Server
# depends_on: [ jump-server ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: worker1-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "worker1_az1"
networks:
port: { get_resource: worker1-server-port }
###########################################################################################################
################### worker 2 – Net 1 – AZ 1 ##############################################################################
# Create a new port for the server interface, assign an ip address and security group
worker2-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az1 }
network_id: { get_resource: kube_private_net_az1 }
security_groups: [{ get_resource: lbaas_security_group }, { get_param: default_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
worker2-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az1 }
name: "worker2-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
worker2-server:
type: OS::Nova::Server
# depends_on: [ jump-server ]
properties:
key_name: { get_param: key_az_1 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: worker2-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "worker2_az1"
networks:
port: { get_resource: worker2-server-port }
##########################################################################################################
################### worker 3 – Net 1 – AZ 2 ################################################################
# Create a new port for the server interface, assign an ip address and security group
worker3-server-port:
type: OS::Neutron::Port
properties:
availability_zone: { get_param: az2 }
network_id: { get_resource: kube_private_net_az2 }
security_groups: [{ get_resource: lbaas_security_group }, { get_param: default_security_group }]
allowed_address_pairs:
ip_address: { get_param: kube_service_network }
ip_address: { get_param: kube_pod_network }
# Create a system volume for use with the server
worker3-sys-vol:
type: OS::Cinder::Volume
properties:
availability_zone: { get_param: az2 }
name: "worker3-boot-vol"
size: 30
volume_type: "M1"
image : { get_param: k5_image }
# Build a server using the system volume defined above
worker3-server:
type: OS::Nova::Server
# depends_on: [ jump-server ]
properties:
key_name: { get_param: key_az_2 }
image: { get_param: k5_image }
flavor: { get_param: flavor }
admin_user: k5user
metadata: { "fcx.autofailover": True }
block_device_mapping: [{"volume_size": "30", "volume_id": {get_resource: worker3-sys-vol}, "delete_on_termination": True, "device_name": "/dev/vda"}]
name: "worker3_az2"
networks:
port: { get_resource: worker3-server-port }
###########################################################################################################

view raw
K5_HA_Kubernetes.yml
hosted with ❤ by GitHub

Notes: I’m no Kubernetes guru – these are example Heat templates that will enable you to get Kubernetes up and running quickly on Fujitsu K5 for evaluation purposes. They have not been designed with production workloads in mind. Kubernetes is still a relatively young product that needs enhancements to it’s multi-tenancy and security components before it will be ready for the general enterprise production market – unless of course you have a team of developers who are keen to get coding – that’s the beauty of open source initiatives.

The Kubernetes LoadBalancer TYPE is API compatible with GCE, surprise, surprise and also AWS. Though I have attempted to stick a K5 LoadBalancer in front of the minions it looks like it needs more debug as I only get partial page returns and have run out of time to debug further….I get to play with Kubernetes by nights only at present. As we don’t use a native OpenStack LBaaS v1 or v2, these weren’t fit-for-purpose at K5 deployment time, unfortunately I could not leverage their Kubernetes LBaaS solution either.

If you do need a production grade solution on K5, Kubernetes has been deliberately architected to facilitate plugins so it wouldn’t be that difficult to ‘roll your own’ LBaaS API. And thanks to the community spirit, Concur, has already done most of the hard work for us providing a helper template here – https://github.com/concur/kubegowatcher.

Deployment Prerequisites

Please pay close attention to the input parameters and ensure that you configure them to match you environment before deployment.

Once deployed login to the JumpBox and from there you can access all the kube nodes.

Useful Commands:

# check version
kubectl version
# list kube nodes
kubectl get nodes
# list pods
kubectl get pods –all-namespaces
# check docker
sudo docker ps
# deploy demo application
kubectl create -f "https://github.com/microservices-demo/microservices-demo/blob/master/deploy/kubernetes/complete-demo.yaml?raw=true"
# check application status
kubectl get pod –namespace=sock-shop
# view the application service
kubectl describe svc front-end -n sock-shop
# delete demo application
kubectl delete -f "https://github.com/microservices-demo/microservices-demo/blob/master/deploy/kubernetes/complete-demo.yaml?raw=true"

view raw
Kubectl.txt
hosted with ❤ by GitHub

Happy Stacking!

#withk5youcan

Leave a Reply

Fill in your details below or click an icon to log in:

WordPress.com Logo

You are commenting using your WordPress.com account. Log Out /  Change )

Google photo

You are commenting using your Google account. Log Out /  Change )

Twitter picture

You are commenting using your Twitter account. Log Out /  Change )

Facebook photo

You are commenting using your Facebook account. Log Out /  Change )

Connecting to %s
